TMOS10-12030 for STHS34PF80 EVK

$600
10 days
+
Add to wish list
Shipping method
Payment options
Our advantages
  • Best optical performance at IR
  • Qualified with global buyers
  • Handful experience with R&D
ColorBLACK Size15.5mm*16.5mm
Lens TMOS10-12030 for TMOS EVK
(Patented Lens for wall mounted movement/presence detector, optimized for TMOS sensor)


This document specifies TMOS sensor STHS34PF80 from STMicroelectronics, PCB TMOS_34PF80Rev2.1_noled_FrontCable and Lens TMOS10-12030   from Fresnel Factory Inc.


Dimension and orientation of TMOS10-12030 lens





Please Note, that Center of Optical Window of the Sensor must be coincident with axis of symmetry of the Lens



   Detectable Range and Field of View

Housing for EVK with PCB TMOS_34PF80 Rev2.1_noled_FrontCable



Please download 3D STP file for 3D printing in link below.

Part 1

https://drive.google.com/file/d/1gRLProJSniz-w73UoOP3jUCJCDAWmtuV/view?usp=drive_link

Part 2

https://drive.google.com/file/d/1ifLi_9dXg2PMuxtvUOR00OGqNd8uZ_bV/view?usp=drive_link

Part 3

https://drive.google.com/file/d/1kX6LlXAk8CNt7Qe363yhO-WZ90OMo1x0/view?usp=drive_link



Housing consists 3 Parts with Directional Keys. All keys must be faced to the PCB connector (see picture below). Housing fastened by 4 Philips self-tapping Screws M2x8.




PCB TMOS_34PF80Rev2.1_noled_FrontCable
